OPERATION

B–64124EN/01

12. GRAPHICS FUNCTION

713

The first six functions above (1. to 6.) are available by setting the graphic

parameters. The seventh to ninth functions (

7. to 9.) are mainly executed

using soft keys after drawing has been setup. The tenth function (

10.) is

enabled by setting a parameter. The eleventh function (

11.) can be used

at any time.

Path drawing procedure

1 To draw a tool path, necessary data must be set beforehand.

So press the function button

CUSTOM

GRAPH

some times. The “PATH

GRAPHIC (PARAMETER)” is displayed.

MDI

* * * *

* * * * * *

14 : 25 : 07

PATH GRAPHIC (PARAMETER–1) O0000 N00002

AXES P=

(XY=0, YZ=1, ZY=2, XZ=3, XYZ=4, ZXY=5, 2P=6)

ANGLE

ROTATION A= 0

TILTING A= 0

SCALE K= 0.00

CENTER OR MAX./MIN.

X=130.000 Y= 110.000 Z= 50.000

I= 0.000 J= –10.000 K= 0.000

START SEQ. NO. N= 0

END SEQ. NO. N= 0

NO. A=

PARAM

POS

EXEC

SCALE

MDI

* * * *

* * * * * *

14 : 25 : 51

PATH GRAPHIC (PARAMETER–2) O0000 N00001

TOOL. COMP P=

COLOR (0123456)

PATH P= 0

TOOL Q= 0

AUTO CHANGE R= 0

PARAM

POSEXEC SCALE

2 There are two screens for setting drawing parameters.

Press the page key according to the setting items for selecting

screens.

3 Set the cursor to an item to be set by cursor keys.

4 Input numerics by numeric keys.

Procedure
