APPENDIXG. ALARM LIST

B–64124EN/01

874

No. DescriptionFaulty location and remedy

SPM

indica-

tion(*1)

Message

9055 SPN_n_ : POWER LINE

SWITCH ER-

ROR

55 1 Replace the magnetic contactor.

2 Check and correct the sequence.

The power line state signal of the

magnetic contactor for selecting a

spindle or output is abnormal.

9056 SPN_n_ : INNER COOL-

ING FAN STOP

56 Replace the SPM unit. The cooling fan in the SPM control

circuit stopped.

9057 SPN_n_ : EX DECEL-

ERATION

POWER

57 1 Decrease the acceleration/decel-

eration duty.

2 Check the cooling condition (pe-

ripheral temperature).

3 If the cooling fan stops, replace the

resistor.

4 If the resistance is abnormal, re-

place the resistor.

An overload was detected in the re-

generative resistance. (PSMR alarm

indication: H)

Thermostat operation or short–time

overload was detected.

The regenerative resistor was dis-

connected, or an abnormal resis-

tance was detected.

9058 SPN_n_ : OVERLOAD IN

PSM

58 1 Check the PSM cooling status.

2 Replace the PSM unit.

The temperature of the radiator of the

PSM has increased abnormally.

(PSM alarm indication: 3)

9059 SPN_n_ : COOLING FAN

STOP IN PSM

59 Replace the SPM unit. The cooling fan in the PSM stopped.

(PSM alarm indication: 2)

9061 61 Check the parameter settings. An error between the semi–closed

loop and full–closed loop is exces-

sive during use of the dual position

feedback function.

9065 65 1 Check the parameter settings.

2 Check the sensor connection and

signal.

3 Check the power line connection.

A travel distance is excessive during

pole determination.

9073 SPN_n_ : MOTOR SEN-

SOR DISCON-

NECTED

73 1 Replace the feedback cable.

2 Check the shield processing.

3 Check and correct the connection.

4 Adjust the sensor.

The motor sensor feedback signal is

not present.

9074 SPN_n_ : CPU TEST ER-

ROR

74 Replace the SPM control printed–cir-

cuit board.

An error was detected in a CPU test.

9075 SPN_n_ : CRC ERROR 75 Replace the SPM control printed–cir-

cuit board.

An error was detected in a CRC test.

9079 SPN_n_ : INITIAL TEST

ERROR

79 Replace the SPM control printed–cir-

cuit board.

An error was detected in an initial test

operation.

9081 SPN_n_ : 1–ROT MO-

TOR SENSOR

ERROR

81 1 Check and correct the parameter.

2 Replace the feedback cable.

3 Adjust the sensor.

The one–rotation signal of the motor

sensor cannot be correctly detected.

9082 SPN_n_ : NO 1–ROT

MOTOR SEN-

SOR

82 1 Replace the feedback cable.

2 Adjust the sensor.

The one–rotation signal of the motor

sensor is not generated.

9083 SPN_n_ : MOTOR SEN-

SOR SIGNAL

ERROR

83 1 Replace the feedback cable.

2 Adjust the sensor.

An irregularity was detected in a mo-

tor sensor feedback signal.
