OPERATION8. DATA INPUT/OUTPUT

B–64124EN/01

554

All pitch error compensation data are output in the defined format from

the memory of the CNC to a floppy or NC tape.

Outputting Pitch Error Compensation Data

1 Make sure the output device is ready for output.

For the two–path control, select the tool post for which pitch error

compensation data to be input is used with the tool post selection

switch.

2 Specify the punch code system (ISO or EIA) using a parameter.

3 Press the EDIT switch on the machine operator’s panel.

4 Press function key

SYSTEM

5 Press the rightmost soft key

(next–menu key) and press chapter

selection soft key

[PITCH].

6 Press soft key

[(OPRT)].

7 Press rightmost soft key

(next–menu key).

8 Press soft keys [PUNCH] and [EXEC].

All parameters are output in the defined format.

Output format is as follows:

N 10000 P ;. . .

N 11023 P ;. . . . . .

N : Pitch error compensation point No. +10000. . .

P : Pitch error compensation data. . .

When bi–directional pitch error compensation is used, output format is

as follows :

N20000 P.... ;

N21023 P.... ;

N23000 P.... ;

N24023 P.... ;

N : Pitch error compensation point + 20000

P : Pitch error compensation data

When the floppy disk directory display function is used, the name of the

output file is

“PITCH ERROR”.

8.6.4

Outputting Pitch Error

Compensation Data

Procedure

Explanations

D Output format

D Output file name
