B-63322EN/03 NC FUNCTIONS 7.COORDINATE SYSTEM

- 99 -

7.4 PLANE SELECTION

Select the planes for circular interpolation, cutter compensation, and

drilling by G-code. The following table lists G-codes and the planes

selected by them.

Explanation

Table7.4 Plane selected by G code

G code Selected plane Xp Yp Zp

G17 Xp Yp plane

G18 Zp Xp plane

G19 Yp Zp plane

X-axis or an

axis parallel to

Y-axis or an

axis parallel to

Z-axis or an

axis parallel to

Xp, Yp, Zp are determined by the axis address appeared in the block in

which G17, G18 or G19 is commanded. When an axis address is

omitted in G17, G18 or G19 block, it is assumed that the addresses of

basic three axes are omitted. Parameter No. 1022 is used to specify that

an optional axis be parallel to the each axis of the X, Y-, and Z-axes as

the basic three axes.

The plane is unchanged in the block in which G17, G18 or G19 is not

commanded.

When the power is turned on or the CNC is reset, G17 (XY plane)or

G18 (ZX plane) is selected by bits 5 (G18) of parameter 2401.

The movement instruction is irrelevant to the plane selection.

Example

- Example 1

When X and U, Y and V, and Z and W are parallel to each other,

respectively

G17 X_ Y_ XY plane

G17 U_ Y_ UY plane

G18 X_ W_ WX plane

G18 U_ W_ WU plane

- Example 2

Planes remain unchanged in blocks for which G17, G18, or G19 is not

specified.

G18 X_ Z_ ZX plane

X_ Y_ Plane not changed (ZX plane)

- Example 3

If G17, G18, or G19 is specified for a block, and no axis address is

specified in that block, the axis addresses for the basic three axes are

assumed to be omitted.

G17 XY plane

G17 X_ XY plane

G17 U_ UY plane
