9.SPINDLE SPEED FUNCTION NC FUNCTIONS B-63322EN/03

- 118 -

9.9 SPINDLE ORIENTATION

You can perform spindle orientation simply by mounting a position

coder on the spindle. Stoppers or pins for physically stopping the

spindle at a specified position are not necessary. A spindle can be

instantly oriented, even when rotating at high speed, thereby greatly

reducing the orientation time.

9.10 SPINDLE OUTPUT SWITCHING

Spindle output switching switches between the two windings, one for

low speed and the other for high speed, incorporated into the special

spindle motors.

This ensures that the spindle motor demonstrates stable output

characteristics over a wide range.
