B-63322EN/03 NC FUNCTIONS 26.PROGRAM EDITING

- 353 -

26.3 ADVANCED PROGRAM EDITING/OPERATION

26.3.1 Automatically Inserting Sequence Numbers

During programming, the sequence number of the next block can be

automatically inserted each time block is inserted.

The initial sequence number and the increment must be set for the

appropriate parameters.

26.3.2 Editing Two Programs Simultaneously

The program text screen can be divided into right and left portions, so

that two programs can be edited simultaneously.

26.3.3 Editing Programs in Operation

During automatic operation, programs can be edited by stopping

automatic operation with the feed hold or single block function.

Automatic operation can then be resumed.

The available editing operations depend on the type of the program that

is being operated.

1 If a main program is being operated

- All editing operations are available

2 If a subprogram is being operated

- If a subprogram is being operated

- Editing is possible only if the operation has been

memory operation.

- Editing is possible in word units only.
