B-63322EN/03 NC FUNCTIONS 20.AXIS CONTROL FUNCTIONS

- 253 -

20.1 FOLLOW-UP

If the machine moves in the state in which position control on

controlled axes is disabled (during servo-off, emergency stop, or servo

alarm), feedback pulses are accumulated in the error counter. The

CNC reflects the machine movement corresponding to the error count

in the current position managed by the CNC. This operation is referred

to as follow-up. When follow-up is performed, the current position

managed by the CNC does not shift from the actual machine position.

You can select whether to perform follow-up for axes for which the

servo is turned off.

Follow-up is always performed during emergency stop or a servo

alarm.

20.2 MECHANICAL HANDLE FEED

It is possible to move the machine by hand, using the mechanical

handle installed on the machine; not by the NC (servo motor).

Move distance by the mechanical handle is followed up and actual

position in

The NC is revised. The mechanical handle feed is done by inputting

the servo off signal of the axis fed. It is necessary, however, to specify

following up of the movement in the servo off status with the follow up

signal.

20.3 SERVO OFF

Place the controlled axes in the servo off state; that is, they stop the

current to the servo motor, which disables position control. However,

the position detection feature functions continuously, so the current

position is not lost. These signals are used to prevent the servo motors

from overloading when the tools on the axes are mechanically clamped

under certain machining conditions on the machine, or to move the

machine by driving the motors by mechanical handles.

20.4 MIRROR IMAGE

The MDI-commanded or the program-commanded move direction of

each axis can be reversed and executed.

Mirror image is set by MDI setting or by input signals from PMC.

Mirror image can be applied to each axis.
