10.TOOL FUNCTION NC FUNCTIONS B-63322EN/03

- 122 -

10.1 TOOL SELECTION FUNCTION

For tool selection, an address T followed by a numeric value of no more

than 10 digits can be used to specify a tool number.

When a T code is specified, the code signal corresponding to the tool

number and strobe signal are output for tool selection on the machine.

This code signal is held until the next T code is specified.

Only one T code can be specified in a block. The maximum allowable

number of digits can be specified using parameter No. 2032, and an

alarm can be issued when a value greater than the specified maximum

allowable number of digits is specified.

Table 10.1 Maximum Allowable Numbers of Digits Specifiable in T Code and

Specifiable Ranges

Parameter No.

2032 for

specifying the

maximum

allowable number

of digits

Parameter TSN

(No. 2003#2) for

enabling/disablin

g negative value

specification

Specifiable range

Disable 0 to 9

Enable -9 to 9

Disable 0 to 99

Enable -99 to 99

Disable 0 to 999

Enable -999 to 999

Disable 0 to 9,999

Enable -9,999 to 9,999

Disable 0 to 99,999

Enable -99,999 to 99,999

Disable 0 to 999,999

Enable -999,999 to 999,999

Disable 0 to 9,999,999

Enable -9,999,999 to 9,999,999

Disable 0 to 99,999,999

Enable -99,999,999 to 99,999,999

Disable 0 to 999,999,999

Enable -999,999,999 to 999,999,999

10 Disable 0 to 4,294,967,295
