15i/150i-Model A Descriptions Page 22

Descriptions

Page of 422

/ 422

2.LIST OF SPECIFICATIONS GENERAL B-63322EN/03



Item Specifications

Series 15i

Series 150i

Overtravel AA

Stored stroke check 1 AA

Stored stroke check 2 CC

External stroke limit setting CC

Stroke limit check before travel CC

Mirror image Each axis AA

Follow-up At emergency stop and at Servo alarm and so on AA

Servo-off/mechanical handle feed AA

Backlash compensation AA

Separate backlash compensation for rapid

traverse and cutting feed

Stored pitch error compensation CC

Interpolated pitch error compensation CC

Periodical secondary pitch error

compensation

Gradient compensation CC

Straightness deviation compensation CC

Position switch CC

Absolute position detection AA

Feed forward for rapid traverse AA

Abnormal load detection CC

Straightness compensation at 128 points CC

Interpolation type straightness compensation CC

Bi-directional pitch error compensation CC

Three-dimensional error compensation CC

Linear motor AA

Level-up HRV control AA

Fine acceleration/deceleration AA

Operation

Automatic operation DNC operation (Reader/puncher interface is required)

Memory operation

MDI operation

DNC operation with memory card AA

Cycle start/Feed hold AA

Program stop/Program end AA

Reset/Rewind AA

Program number search AA

Sequence number search AA

Sequence number collation stop AA

Program restart CC

Block restart CC

Tool retract & recover CC

Active block cancel CC

Buffer register AA

Multi buffer (5 blocks) AA

Multi buffer (15 blocks) CC

Multi buffer (100 blocks) CC

Dry run AA

Single block AA
