Power Mate D and F Motion Controllers Programming manual Page 127

Programming manual

Page of 373

/ 373

15.

CUSTOM MACRO

15.5

External Output Commands

(iii) EOB code is output by setting data

IS0

on the parameter screen after the

command data output.

(iv)

“vacant” variable is outputtable as 0.

(b) DPRNT

. ..I....

(ii)

Number of digits

below decimal point

Number of digits

above

decimai

point

Variable

Character

When DPRNT is specified, characters and numeric characters and every

variable value digit are output by a code set by setting data

(ISO).

The description of the commands is same as in (i), (iii), (iv) of BPRNT

command.

For outputting variable values, specify the variabie number following number

of digits below the decimal point by parenthesizing these values.

Variable values are output by the specified number of digits, every digit

starting with a higher significant digit by a code set by setting data

(ISO).

The decimal point is also output by a code set by setting data

(ISO).

A variable value is regarded as being composed of a max.

8-digit

numeric

value.

If the higher significant digits are 0, they are not output when

parameter PRT (No.

6001#1)

= 1, and the space code is output when

PRT =

Whenever the number of digits below the

decimal point is other than 0, the

numeric value below the decimal point is output.

When the number of digits

below the decimal point is 0, the decimal point is not output.

For the plus

(

)

code in case of a positive sign, the space code is output

when parameter PRT (No.

6OOl#l)

=0, but no code is output when

PRT=l.

(Example 1)

BPRNT

[C”x#lOO

[3]

YHOl

[3]

M#lO

[0]

]

Variable value

00 = 0.40956

#lOl=

1638.4

#lo=

12.34

(oooooooc)

-1638400

(FFE70000)

110

(0000019A)

space

I-104
