15. CUSTOM MACRO

15.6

Pattern Data Input Function

15.6 Pattern Data Input Function

This function -enables the. user to create CNC programs only by selecting numeric

data (pattern data) from drawings and entering the data through the

CRT/MD&

without

using the conventional CNC language.

For example, the machine tool builder can freely set drilling cycles, such as the boring

cycle and tapping cycle, using the custom macro function, and register them in

program memory.

(1)

Each of the above cycles is assigned a pattern name such as

BOW,

TAP3, or

DRL2. The operator can select the desired pattern from the pattern name

menu ‘displayed on the CRT.

(2)

The drilling cycles must be set in such a way that variables are used for values

(pattern data) that need to be specified by the operator.

The variables can be assigned pattern names such

as DEPTH, ESCAPE,

FEED, and MATERIAL. The operator assigns values

(pattern data) to these

names.

156.1

Displaying the pattern menu

Select the custom macro variable screen by pressing the OFFSET/SETTING button,

then press the

MENUNAR

button again. The following pattern menu appears on the

screen.

: HOLE PATTERN

00011

NO0011

BORING

TAPPING

3. DRILLING

PECK

SPOT

COUNTER

Reverse

tapping

8. Rigid tapping

BACK

10. Test pattern

MDI

+++*

+++ +++

16:26:30

[MACRO][

MENU ][ OPR

][

W-T)

HOLE PATTERN: A string of up to 12 characters can be specified for a menu title.

BORING: A string of up to 10 characters can be specified for a pattern name.

(Kanji and katakana characters can be used in the character strings.)

The manufacturer programs

the

character strings for the menu titles and pattern

names using the custom macro, and registers them in program memory as a sub-

program with program No. 9500.

I-107
