B–63380EN/02
4. DESCRIPTION OF PARAMETERS
9
#7
0000
#6 #5
SEQ
#4 #3 #2
INI
#1
ISO
#0
TVC
Setting entry is acceptable.
[Data type] Bit
TVC TV check
0 : Not performed
1 : Performed
ISO Code used for data output
0 : EIA code
1 : ISO code
INI Unit of input
0 : In mm
1 : In inches
SEQ Automatic insertion of sequence numbers
0 : Not performed
1 : Performed
When a program is prepared by using MDI keys in the part program
storage and edit mode, a sequence number can automatically be assigned
to each block in set increments. Set the increment to parameter 3216.
#7
0002
#6 #5 #4 #3 #2 #1 #0
SJZ
Setting entry is acceptable.
[Data type] Bit
SJZ Manual reference position si performed as follows:
0 : When no reference position has been set, reference position return is
performed using deceleration dogs. When a reference position is
already set, reference position return is performed using rapid traverse
and deceleration dogs are ignored.
1 : Reference position return is performed using deceleration dogs at all
times.
NOTE
SJZ is enabled when bit 3 (HJZ) of parameter No.1005 is set
to 1. When a reference position is set without a dog, (i.e.
when bit 1 (DLZ) of parameter No.1002 is set to 1 or bit 1
(DLZx) of parameter No.1005 is set to 1) reference position
return after reference position setting is performed using
rapid traverse at all times, regardless of the setting of SJZ.
4.1
PARAMETERS OF
SETTING
