4. DESCRIPTION OF PARAMETERS
B–63380EN/02
22
#7
1005
#6 #5 #4 #3
HJZx
#2 #1
DLZx
DLZx
#0
ZRNx
ZRNx
[Data type] Bit axis
ZRNx When a command specifying the movement except for G28 is issued in
automatic operation (MEM, RMT, or MDI) and when a return to the
reference position has not been performed since the power was turned on
0 : An alarm is generated (P/S alarm 224).
1 : An alarm is not generated.
NOTE
The state in which the reference position has not been
established refers to that state in which reference position
return has not been performed after power–on when an
absolute position detector is not being used, or that state in
which the association of the machine position with the position
detected with the absolute position detector has not been
completed (see the description of bit 4 (APZx) of parameter
No. 1815) when an absolute position detector is being used.
DLZx Function for setting the reference position without dogs
0 : Disabled
1 : Enabled
NOTE
When bit 1 (DLZ) of parameter No.1002 is 0, DLZx is
enabled. When bit 1 (DLZ) of parameter No.1002 is 1, DLZx
is disabled, and the function for setting the reference
position without dogs is enabled for all axes.
HJZx When a reference position is already set:
0 : Manual reference position return is performed with deceleration sogs.
1 : Manual reference position return is performed using rapid traverse
without deceleration dogs, or manual reference position return is
performed with deceleration dogs, depending on the setting of bit 7
(SJZ) of parameter No.0002.
NOTE
When reference position return without dogs is specified,
(when bit 1 (DLZ) of parameter No.1002 is set to 1 or bit
(DLZx) of parameter No.1005 is set to 1) reference position
return after a reference position is set is performed using
rapid traverse, regardless of the setting of HJZ.
