Series 20i-MODEL A Parameter manual Page 201

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
197
AFS Whether to display the actual cutting feedrate and actual spindle speed
0 : Does not display the actual cutting feedrate and actual spindle speed.
1 : Displays them.
Z*T This parameter is related to the movement of the tool along the Z–axis.
0 : In guided pocketing, teaching cannot be carried out if different
feedrates are specified for the Z–axis and the X– and Y–axes.
The tool returns to the R–point at the end of boring.
1 : In guided pocketing, teaching can be carried out by specifying
different feedrates for the Z–axis and the X– and Y–axes.
The tool returns to the initial point at the end of boring.
CIA In circular inside facing, the tool moves from the approach auxiliary point
to the approach start point at the:
0 : Maximum feedrate.
1 : Regular feedrate for a cutting allowance.
SFN Whether to output the S command when forward/reverse spindle rotation
is specified
0 : Does not output the S command.
1 : Outputs the S command.
GRS Whether to turn the GSP signal on when the reset signal is turned on
during execution of machining guidance
0 : Turns the GSP signal on.
1 : Does not turn the GSP signal on.
9324 Program number of a teaching program
This parameter sets the program number for storing a teaching program in
memory.
For example, when a value of 100 is set, teaching data is registered in
memory with program number O100. When this parameter is set to 0, the
teaching program number is automatically set to 7999.
For the 20i–TA, when a negative value is set, the multi–program teaching
function is enabled.
9325 Dummy program number for playback execution
This parameter sets the dummy program number for playback execution
when no program is registered in memory.
When this parameter is set to 0, a program number of O7998 is
automatically created.
9326 System parameter
9327 System parameter
The users cannot use these parameters because the parameters are used as
system parameters.
