Series 20i-MODEL A Parameter manual Page 146

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63380EN/02
142
5132
Depth of cut in multiple repetitive canned cycles G71 and G72
[Data type] 2–word
Increment system IS-B IS-C Unit
Millimeter input 0.001 0.001 mm
Inch input 0.0001 0.0001 inch
[Valid data range] 0 to 99999999
This parameter sets the depth of cut in multiple repetitive canned cycles
G71 and G72.
5133
Escape in multiple repetitive canned cycles G71 and G72.
[Data type] 2–word
Increment system IS-B IS-C Unit
Millimeter input 0.001 0.001 mm
Inch input 0.0001 0.0001 inch
[Valid data range] 0 to 99999999
This parameter sets the escape in multiple repetitive canned cycle G71
and G72.
5135
Escape in multiple repetitive canned cycle G73 in X–axis direction
5136
Escape in multiple repetitive canned cycle G73 in Z–axis direction
[Data type] 2–word
Increment system IS-B IS-C Unit
Input in mm 0.001 0.001 mm
Input in inches 0.0001 0.0001 inch
[Valid data range] –99999999 to 99999999
This parameter sets the escape in multiple repetitive canned cycle G73 of
an X, then Z axis.
5137
Division count in multiple repetitive canned cycle G73
[Data type] 2–word
[Unit of data] Cycle
[Valid data range] 1 to 99999999
This parameter sets the division count in multiple repetitive canned cycle
G73.
4.16.3
Parameter of Multiple
Repetitive Canned
Cycle
[Unit of data]
[Unit of data]
[Unit of data]
