Series 20i-MODEL A Parameter manual Page 97

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
93
#7
3118
#6 #5 #4 #3 #2 #1 #0
AS1
[Data type] Bit
AS1 When the actual spindle speed (SACT) of the first spindle is displayed,
each value is:
0 : The value calculated based on the feedback pulses from the position
coder.
1 : The value calculated from the spindle motor speed (the same as the
spindle speed displayed on the operating monitor screen).
3120
Time from the output of an alarm to the termination of sampling (waveform diag-
nosis function)
[Data type] Word
[Unit of data] ms
[Valid data range] 1 to 32760
When the waveform diagnosis function is used, this parameter sets the
time form the output of a servo alarm until data collection. Storage
operation is stopped because of the alarm. (This means that the
termination of data collection can be delayed by a specified time.)
3122 Time interval used to record time data in operation history
[Data type] Word
[Unit of data] Minutes
[Valid data range] 0 to 1439
Time data is recorded in operation history at set intervals. When 0 is
specified in this parameter, 10 minutes is assumed as the default.
However, time data is not recorded if there is no data to be recorded at the
specified time.
3123 Time until screen clear function is applied
[Data type] Byte
[Unit of data] Minutes
[Valid data range] 1 to 255
This parameter specifies the period that must elapse before the screen
clear function is applied. If 0 is set, the screen is not cleared.
