Series 20i-MODEL A Parameter manual Page 199

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
195
#7
9000
#6 #5 #4
RSTC
#3 #2 #1 #0
RSTC Whether to set common variables #100 to #149 to null when the CNC is
reset
0 : Does not set common variables #100 to #149 to null.
1 : Sets common variables #100 to #149 to null.
For the 20i–FA/TA FANUC sample program, always set 1.
#7
9321
#6 #5 #4
R28
#3
GRC
#2 #1
WS0
#0
WS0 Whether to clear the workpiece shift amount to 0 at power–on
0 : Does not clear the workpiece shift amount to 0.
1 : Clears it to 0.
GRC Machining mode for grooving (in the Z–axis direction)
0 : Performs bidirectional in–feed machining for grooving in the Z–axis
direction.
1 : Performs unidirectional in–feed machining for grooving in the Z–axis
direction.
R28 Number of figures that can be specified for roughing
0 : Allows up to five figures to be specified.
1 : Allows up to 28 figures to be specified.
#7
PRD
9322
#6
CPS
#5 #4 #3 #2
PLS
PLS
#1
RCF
RCF
#0
CMT
CMT
CMT Whether to store each machining name as a comment during teaching
0 : Does not store each machining name as a comment.
Example) G01 X10 Y80 Z5; (for linear machining)
1 : Stores each machining name as a comment.
Example) G01(LINE) X10 Y80 Z5; (for linear machining)
RCF Screen to be automatically displayed when teaching is terminated by
pressing the [TEACHEND] soft key
0 : Teaching confirmation screen
1 : Current position display screen
PLS When the initial screen is erased
0 : Displays the initial screen until soft key [START] is clicked.
1 : Displays the initial screen for three seconds, then erases it.
CPS On the current–position display screen, the specified spindle rotation
speed is:
0 : Not displayed.
1 : Displayed.
PRD The valid input range for dwell data is:
0 : 0 to 9999.999 (0 to 9999.999 seconds)
1 : 0 to 9999 (0 to 0.999 seconds)
