Series 20i-MODEL A Parameter manual Page 87

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
83
#7
3100
#6 #5 #4 #3 #2 #1
CEM
#0
[Data type] Bit
CEM On screens such as the operation history screen and help screen, keys on
the MDI panel are indicated:
0 : In English.
1 : With graphics qualifying for CE marking. (A character generator
supporting graphics qualifying for CE marking is required.)
#7
3101
#6 #5 #4
BGD
#3 #2
CPG
#1
KBF
#0
FSK
[Data type] Bit
FSK Whether to use function selection soft keys
0 : Uses (displays) function selection soft keys.
1 : Does not use (display) them.
NOTE
Function selection soft keys are soft keys which provide the
same functions as function keys on the MDI panel (<POS>,
<PROG>, <SYSTEM>, etc.). They are used to select a
screen.
Always set this parameter to 0 when the MDI panel has no
function key.
KBF When the screen or mode is changed, the contents of the key–in buffer are:
0 : Cleared.
1 : Not cleared.
NOTE
When KBF = 1, the contents of the key–in buffer can all be
cleared at one time by pressing the <SHIFT> key followed
by the <CAN> key.
CPG Whether to enable cursor movement and page change by <CAN> +
numeric keys
0 : Disables these operations.
1 : Enables them.
4.11
PARAMETERS OF
MDI, DISPLAY,
AND EDIT
