Series 20i-MODEL A Parameter manual Page 178

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63380EN/02
174
6756
Integrated value of general–purpose integrating meter drive signal (TMRON)
ON time II
Setting entry is acceptable.
[Data type] 2–word
[Unit of data] One minute
[Valid data range] 0 to 99999999
This parameter displays the integrated value of a time while input signal
TMRON from PMC is on.
The actual integrated value is the sum of the value specified by parameter
No. 6755 and that specified by parameter No. 6756.
6757 Operation time (integrated value of one automatic operation time) I
Setting entry is acceptable.
[Data type] 2–word
[Unit of data] One ms
[Valid data range] 0 to 60000
6758 Operation time (integrated value of one automatic operation time) II
Setting entry is acceptable.
[Data type] 2–word
[Unit of data] One minute
[Valid data range] 0 to 99999999
This parameter displays the one automatic operation drive time (neither
stop nor hold state included).
The actual integrated value is the sum of the value specified by parameter
No. 6757 and that specified by parameter No. 6758.
The operation time is automatically preset to 0 during the power–on
sequence and the cycle start from the reset state.
