Series 20i-MODEL A Parameter manual Page 83

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
79
#7
MHI3001
#6 #5 #4 #3 #2
RWM
#1 #0
[Data type] Bit
RWM RWD signal indicating that rewinding is in progress
0 : Output only when the tape reader is being rewound by the reset and
rewind signal RRW
1 : Output when the tape reader is being rewound or a program in
memory is being rewound by the reset and rewind signal RRW
MHI Exchange of strobe and completion signals for the M, S and T codes
0 : Normal
1 : High–speed
#7
3002
#6 #5 #4
IOV
#3 #2 #1 #0
[Data type] Bit
IOV For the feedrate override signal, second feedrate override signal, and rapid
traverse override signal:
0 : Negative logic is used.
1 : Positive logic is used.
#7
3003
#6
MVX
MVX
#5
DEC
DEC
#4
DAU
#3
DIT
DIT
#2
ITX
ITX
#1 #0
ITL
ITL
[Data type] Bit
ITL Interlock signal
0 : Enabled
1 : Disabled
ITX Interlock signals for each axis
0 : Enabled
1 : Disabled
DIT Interlock for each axis direction
0 : Enabled
1 : Disabled
DAU Whether to enable the interlock signal for each axis when bit 3 of
parameter No. 3003 (DIT) is set to 0
0 : Enables the interlock signal during manual operation and disables it
during automatic operation.
1 : Enables the interlock signal during both manual and automatic
operation.
DEC Deceleration signal (*DEC1 to *DEC4) for reference position return
0 : Deceleration is applied when the signal is 0.
1 : Deceleration is applied when the signal is 1.
MVX The axis–in–movement signal is set to 0 when:
0 : Distribution for the axis is completed. (The signal is set to 0 in
deceleration.)
1 : Deceleration of the axis is terminated, and the current position is in the
in–position.
