4. DESCRIPTION OF PARAMETERS
B–63380EN/02
40
When the machine requires little change in cutting feedrate during
cutting, a cutting feedrate can be specified in the parameter. This
eliminates the need to specify a cutting feedrate in the NC program.
The feedrate set in this parameter is effective between the CNC being
cleared by a power–on or reset and a feedrate being specified using a
program command (F command). A feedrate becomes effective as soon
as it has been specified by an F command.
1415
Linear or circular jog feedrate (feed per revolution)
[Data type] Double–word type
Unit Range of valid settings
Millimeter machine 0.01 mm/min 6 to 32767
Inch machine 0.001 inch/min 6 to 32767
This parameter sets the feedrate of linear or circular jog feed (feed amount
per spindle revolution) when the jog feedrate override is 100%.
NOTE
1 This parameter is valid when bit 4 of parameter No. 1402
(JRV) is set to 1 (feed per revolution).
2 This parameter is used as the feedrate of linear and circular
machining using the machining guidance function. (The
machining guidance function feeds the tool along two axes
(along a straight line with an angle or a circle) by jog feed
(linear or circular feed).) The system is controlled so that the
feedrate set for this parameter is used for the feedrate in the
linear direction or along the tangent of the circle.
3 The set feedrate can be overridden within a range of 0.01
to 655.34% using the jog feedrate override signal.
1420 Rapid traverse rate for each axis
[Data type] 2–word axis
Increment system
Unit of data
Valid data range
I
ncremen
t
sys
t
em
U
n
it
o
fd
a
t
a
IS-B IS-C
Millimeter machine 1 mm/min 30 to 240000 6 to 100000
Inch machine 0.1 inch/min 30 to 96000 6 to 48000
Rotation axis 1 deg/min 30 to 240000 6 to 100000
Set the rapid traverse rate when the rapid traverse override is 100% for
each axis.
1421 F0 rate of rapid traverse override for each axis
[Data type] Word axis
Increment system
Unit of data
Valid data range
I
ncremen
t
sys
t
em
U
n
it
o
fd
a
t
a
IS-B IS-C
Millimeter machine 1 mm/min 30 to 15000 30 to 12000
Inch machine 0.1 inch/min 30 to 6000 30 to 4800
Rotaion axis 1 deg/min 30 to 15000 30 to 12000
[Unit of data, valid range]
[Unit of data]
[Valid data range]
[Unit of data]
[Valid data range]
