Series 20i-MODEL A Parameter manual Page 95

Parameter manual
B–63380EN/02
4. DESCRIPTION OF PARAMETERS
91
NOTE
When the values of MS0 and MS1 are changed, all preserved
external operator message history data is cleared.
#7
3114
#6 #5
IUS
#4
IMS
#3
ISY
#2
IOF
#1
IPR
#0
IPO
[Data type] Bit
IPO When the <POS> function key is pressed while the position display
screen is being displayed:
0 : The screen is changed.
1 : The screen is not changed.
IPR When the <PROG> function key is pressed while the program screen is
being displayed:
0 : The screen is changed.
1 : The screen is not changed.
IOF When the <OFFSET/SETTING> function key is pressed while the
offset/setting screen is being displayed:
0 : The screen is changed.
1 : The screen is not changed.
ISY When the <SYSTEM> function key is pressed while the system screen is
being displayed:
0 : The screen is changed.
1 : The screen is not changed.
IMS When the <MESSAGE> function key is pressed while the message screen
is being displayed:
0 : The screen is changed.
1 : The screen is not changed.
IUS When the <CUSTOM/GRAPH> function key is pressed while the user or
graph screen is being displayed:
0 : The screen is changed.
1 : The screen is not changed.
#7
3115
#6
D10x
#5 #4 #3
NDFx
NDFx
#2 #1
NDAx
NDAx
#0
NDPx
NDPx
[Data type] Bit axis
NDPx Display of the current position for each axis
0 : The current position is displayed.
1 : The current position is not displayed.
NDAx Position display using absolute coordinates and relative coordinates is:
0 : Performed.
1 : Not performed. (Machine coordinates are displayed.)
NDFx To the actual speed display, axis movement data is:
0 : Added.
1 : Not added.
