4. DESCRIPTION OF PARAMETERS
B–63380EN/02
94
#7
D083124
#6
D07
#5
D06
#4
D05
#3
D04
#2
D03
#1
D02
#0
D01
D163125 D15 D14 D13 D12 D11 D10 D09
D243126 D23 D22 D21 D20 D19 D18 D17
3127 D25
[Data type] Bit
Dxx (xx: 01 to 25) When modal G code is displayed on the program check screen, the xx
group G code is:
0 : Displayed.
1 : Not displayed.
NOTE
Set these parameters when using the display with seven
soft keys.
3132 Axis name (absoulute coordinate) for current position display
3133 Axis name (relative coordinate) for current position display
[Data type] Byte axis
[Valid data range] 0 to 255
These parameters set the axis name for current position display.
When G code system B or C is used, the axis name set in parameter
No.3132 is used for both absolute and relative coordinate axes.
The values set in these parameters are used only for display. For a
command address, the axis name set in parameter No.1020 is used.
When 0 is specified in these parameters, the value set in parameter
No.1020 is used.
3134 Axis display order on workpiece coordinate system screen and workpiece shift screen
[Data type] Byte axis
[Valid data range] 0, 1 to the number of controlled axes
This parameter specifies the order in which axes are displayed on the
workpiece coordinate system screen and workpiece shift screen (for T
series).
