4. DESCRIPTION OF PARAMETERS
B–63380EN/02
50
1711
Angle (θp) to recognize the inner corner in override
[Data type] Byte
[Unit of data] Degree
[Valid data range]
1 to 179 (standard value = 91)
This parameter sets the angle used to recognize an inner corner for inner
corner override by automatic corner override.
1712
Amount of override for an inner corner
[Data type] Byte
[Unit of data] %
[Valid data range]
1 to 100 (standard value = 50)
Set the amount of override for an inner corner.
1713
Distance Le from the starting point in inner corner override
[Data type] Word
Increment system IS–B IS–C Unit
Millimeter input 0.1 0.01 mm
Inch input 0.01 0.001 inch
[Valid data range] 0 to 3999
Set distance Le from the starting point in an inner comer for corner
override.
1714 Distance Ls up to the ending point in inner corner override
[Data type] Word
Increment system IS–B IS–C Unit
Millimeter input 0.1 0.01 mm
Inch input 0.01 0.001 inch
[Valid data range] 0 to 3999
Set distance Ls up to the end point in an inner corner for corner override.
If qx qp, the inside of a comer is recognized. (q is set in parameter 1711.)
When an inner corner is recognized, the feedrate is overridden in the range
of Le in the block immediately before the intersection of the corner and Ls
in the next block following the intersection.
Ls and Le are each a straight line connecting the intersection of the corner
and a given point on the path of the cutter’s center.
[Unit of data]
[Unit of data]
