Series 20i-MODEL A Parameter manual Page 40

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63380EN/02
36
#7
1401
#6
RDR
RDR
#5
TDR
TDR
#4
RF0
RF0
#3 #2
JZR
#1
LRP
LRP
#0
RPD
RPD
[Data type] Bit
RPD Manual rapid traverse during the period from power–on time to the
completion of the reference position return.
0 : Disabled (Jog feed is performed.)
1 : Enabled
LRP Positioning (G00)
0 : Positioning is performed with non–linear type positioning so that the
tool moves along each axis independently at rapid traverse.
1 : Positioning is performed with linear interpolation so that the tool
moves in a straight line.
JZR The manual reference position return at JOG feedrate
0 : Not performed
1 : Performed
RF0 When cutting feedrate override is 0% during rapid traverse,
0 : The machine tool does not stop moving.
1 : The machine tool stops moving.
TDR Dry run during threading or tapping (tapping cycle G74 or G84, rigid
tapping)
0 : Enabled
1 : Disabled
RDR Dry run for rapid traverse command
0 : Disabled
1 : Enabled
#7
1402
#6 #5 #4
JRV
#3 #2 #1 #0
NPC
NPC
[Data type] Bit
NPC The feed per rotation command is:
0 : Ineffective when a position coder is not provided.
1 : Effective even when a position coder is not provided (because the
CNC converts it to the feed per minute command from F command S
command).
NOTE
Set 0 when a position coder is to be used.
4.7
PARAMETERS OF
FEEDRATE
