Panel i Connection And Maintenance Manual Page 168

Connection And Maintenance Manual
A.PUNCH PANEL FOR PANEL i APPENDIX B-64223EN/01
- 156 -
A.1 OVERVIEW
FANUC PANEL i is provided with the interface connectors for PC
function for example a serial port or a parallel port. But it is not easy
to connect/disconnect cables to these connectors for customer or end
user after PANEL i is integrated in the machine tool because these
connectors are arranged on the rear side of PANEL i.
Punch panel for PANEL i enables user to connect/disconnect cables
with ease.
A.2 SPECIFICATION
Name Specification
Punch panel
(stand alone type)
A08B-0082-C200
FA Full keyboard
with punch panel
(For 15”LCD type, English)
A08B-0082-C151#EC
FA Full keyboard
with punch panel
(For 15”LCD type, Japanese)
A08B-0082-C151#JC
Cable for serial/USB interface A08B-0082-K810
Cable for parallel interface A08B-0082-K811
Punch panel
for PANEL i
Cable for Keyboard/Mouse A08B-0082-K812
