Panel i Connection And Maintenance Manual Page 18

Connection And Maintenance Manual
1.TOTAL CONNECTION DIAGRAMS CONNECTION B-64223EN/01
- 6 -
NOTE
1 Some peripheral devices are not suitable for being
connected to the PANEL i for environmental
durability reasons, and others are not suitable for
use during machine operation. So, carefully read
the operator's manuals of the peripheral devices to
be used.
2 With a unit with a touch panel, the RS232-1
connector (JD33, serial port channel 1) cannot be
used.
3 The keyboard port cannot be used because it is
used by this unit.
4 If a USB device requires a current larger than the
specification of the PANEL i, another power supply
is required.
5 The I/O Link interface is optional.
