E.5 LIST OF THE PCBS, UNITS, MAINTAINANCE
SUPPLIES AND TOOLS
E.5.1 LIST OF PCBS
E.5.1.1
Main PCB
CNC Unit LCD type Specification of Main
PCB
Applied Basic Unit
10.4”VGA
/12.1”
A20B-8101-0360 A08B-0086-B001～4, -B011～4
A13B-0199-B001～4, -B011～4
10.4”SVGA A20B-8101-0368 A08B-0086-B061～4
A13B-0199-B061～4
PANEL i
15.0” A20B-8101-0361 A08B-0086-B021, -B023
A13B-0199-B021, -B023
160i
/180i
/210i
PANEL i for Automotive 15.0” A20B-8101-0364 A08B-0086-B402~3, -B412~3
A13B-0199-B402~3, -B412~3
10.4”VGA A20B-8101-0365
A08B-0086-B501～4
A13B-0199-B502, -B504
10.4”SVGA A20B-8101-0369 A08B-0086-B531～4
A13B-0199-B532, -B534
PANEL i
15.0” A20B-8101-0366
A08B-0086-B521~4
A13B-0199-B522, -B524
300i
PANEL i for Automotive 15.0”
A08B-0086-B422~3, -B432~3
A13B-0199-B422~3, -B432~3
E.5.1.2 Backplane PCB
CNC Specification of Backplane
PCB
Applied Basic Unit
160i /180
i /210i
A20B-8002-0251 A08B-0086-B001～4
A08B-0086-B011～4
A08B-0086-B061～4
A08B-0086-B021, -B023
A08B-0086-B402～3, -B412～3
A13B-0199-B001～4
A13B-0199-B011～4
A13B-0199-B061～4
A13B-0199-B021, -B023
A13B-0199-B402～3, -B412～3
300i A20B-8002-0331 A08B-0086-B422～3, -B432～3
A08B-0086-B501～4
A08B-0086-B521～4
A08B-0086-B531～4
A13B-0199-B422～3, -B432～3
A13B-0199-B502, -B504
A13B-0199-B522, -B524
A13B-0199-B532, -B534
The specifications of the other PCBs are the same as for PANEL i with Pentium
III.
02 05/10/19 Kumakura This page is modified
