Panel i Connection And Maintenance Manual Page 56

Connection And Maintenance Manual
4.CONNECTION TO PERIPHERAL CONNECTION B-64223EN/01
- 44 -
Recommended cable specifications
For RS-232C signals : A66L-0001-0284#10P (0.08 mm
2
, 10 pairs)
For USB ports : Use dedicated cables.
For RS-232C signals and USB ports :
A66L-0001-0285#25P AWG28 25 pairs
Recommended punch panel
For RS-232C signals : A02B-0236-C191(1m), A02B-0236-C192(2m),
A02B-0236-C193(5m)
CAUTION
CNC punch panels (A02B-0120-C191 to
A02B-0120-C193, etc.) other than the panels
indicated above cannot be used with this interface.
Use of such an incorrect punch panel can lead to a
serious problem, e.g., incapability of starting the
system.
Punch panel for RS232-C, USB, parallel port : A08B-0082-C200
Cable for punch panel (A08B-0082-C200) (RS232-C, USB) :
A08B-0082-K810
Cable for punch panel (A08B-0082-C200) (parallel port) :
A08B-0082-K811
Cable for punch panel (A08B-0082-C200) (keyboard, mouse) :
A08B-0082-K812
Recommended connector and housing for cable (JD46 side)
When the A66L-0001-0284#10P is used:
Connector Housing Manufacture
PCR-E20FA PCR-V20LA/PCS-E20LA Honda Tsushin Kogyo
FI30-20S FI-20-CV2/FI-20-CV7 Hirose Electric
FCN-247J020-G/E FCN-240C020-Y/S Fujitsu
52622-2011 52624-2015 Molex Japan
When the A66L-0001-0285#25P is used:
Connector Housing Manufacture
FI40B-20S FI-20-CV5 Hirose Electric
