Panel i Connection And Maintenance Manual Page 216

Connection And Maintenance Manual
B-64223EN/01-04
Title
Draw
No.
Ed. Date Design Description
Date Design. Apprv.
2/19
page
E PANEL i with Pentium M
INDEX
E.1 PREFACE 3
E.2 SPECIFICATIONS 4
E.2.1 PANEL i (For Series 150i/160i/180i/210i/Power Mate i-D/H) 4
E.2.2 PANEL i (For Series 300i/310i/320i) 6
E.2.3 PANEL i for Automotive 8
E.3 CONNECTION TO PERIPHERAL 10
E.3.1 SERIAL PORT 2 10
E.3.2 CONVERSION OF VERTICAL SOFTKEYS AND I/O LINK OF
PANEL i FOR AUTOMOTIVE
10
E.4 OUTLINE DRAWINGS 11
E.4.1 BASIC UNIT 10.4” SVGA LCD TYPE (FOR 160i/180i/210i) 11
E.4.2 BASIC UNIT 10.4”SVGA LCD TYPE (FOR 300i/310i/320i) 12
E.5 LIST OF THE PCBS, UNITS, MAINTAINANCE SUPPLIES AND TOOLS 13
E.5.1 LIST OF PCBS 13
E.5.1.1 Main PCB 13
E.5.1.2 Backplane PCB 13
E.5.2 LIST OF MAINTENANCE UNITS 14
E.5.2.1 Base Unit 14
E.5.3 LIST OF CPU AND MEMORY 15
E.6 CONFIGURATION AND SETTING OF PCB 16
E.6.1 PARTS LAYOUT 16
E.6.2 ADJUSTMENT (Setting of Short Plug on the Main Board) 17
E.6.3 LED DISPLAY (LED on Main Board) 17
E.7 BIOS SETUP 18
E.7.1 HOW to BEGIN THE ‘BIOS SET-UP’ 18
E.8 MAINTENANCE SUPPLIES 19
E.8.1 METHOD OF EXCHANGING CPU UNIT 19
Appendix
