Panel i Connection And Maintenance Manual Page 223

Connection And Maintenance Manual
B-64223EN/01-04
Title
Draw
No.
Ed. Date Design Description
Date Design. Apprv.
9/19
page
Note 1) Key arrangement is different from MDI.
Note 2) In case of A08B-0086- B402, B403, B422, B423, A13B-0199-B402, B403,
B422, B423, vertical soft keys signals go to only PC. In case of
A08B-0086-B412, B413, B432, B433, A13B-0199-B412, B413, B432,
B433, vertical soft keys signals go to both PC and I/O Link. (Refer to
Appendix C “KEY CODE OF SOFT KEYS AND FUNCTION KEYS OF
PANEL i FOR AUTOMOTIVE” about key code to PC.)
Note 3) Please use the external USB cable which length is 1 meter or less when
USB port of Punch panel is used.
Note 4)
Above power consumption includes the following devices.
- PC UNIT, HDD Unit, FAN for HDD, Keyboard, and Mouse.
Above power consumption does not include the following devices.
- FDD Unit, CD-ROM Drive, PCMCIA Card, PCI Extension board, USB
device, and Devices to connect by Serial or Parallel Interface.
Above power consumption is reference. If peripherals are connected or PCI
extended boards are mounted, the power consumption will increase. Also,
please consider the cabinet design and the cooling method, which is most
suitable to the total power consumption.
