Panel i Connection And Maintenance Manual Page 224

Connection And Maintenance Manual
B-64223EN/01-04
Title
Draw
No.
Ed. Date Design Description
Date Design. Apprv.
10/19
page
E.3 CONNECTION TO PERIPHERAL
The section 4. CONNECTION TO PERIPHERAL should be refered about details
which are not described in this section.
E.3.1 SERIAL PORT 2
In case of PANEL i with Pentium M, signals for USB 1 and 2 in this conector
JD46 are not short-circuited with signals for USB 1 and 2 in Section 4.10.
Each ports can be used in the same time.
E.3.2 CONVERSION OF VERTICAL SOFTKEYS AND I/O LINK
OF PANEL i FOR AUTOMOTIVE
The same I/O link conversion function as PANEL i for Automotive with Pentium III
is integrated in the following PANEL i for Automotive.with Pentium M
PANEL i with Pentium M PANEL i with Pentium III
No I/O link conversion
function
A08B-0086-B402, -B403
A08B-0086-B422, -B423
A13B-0199-B402, -B403
A13B-0199-B422, -B423
A08B-0084-B400~B403
A08B-0084-B422, -B423
A13B-0196-B400~B403
A13B-0196-B422, -B423
With I/O link
conversion function
（Vertical softkeys are
usable only in CNC
Not usable in PC）
Non A08B-0084-B410, -B411
A13B-0196-B410, -B411
With I/O link
conversion function
（Vertical softkeys are
usable both in CNC
and PC）
A08B-0086-B412, -B413
A08B-0086-B432, -B433
A13B-0199-B412, -B413
A13B-0199-B432, -B433
A08B-0084-B412, -B413
A08B-0084-B432, -B433
A13B-0196-B412, -B413
A13B-0196-B432, -B433
