PROGRAMMING

11. TOOL FUNCTION

(T FUNCTION)

B–63684EN/01

110

The CNC uses set parameters to control the turret which is indexed for a

tool to be used. A specified T code is output, and at the same time, the

turret is positioned at the location which was specified for the tool on the

tool registration screen. Up to 136 tools can be registered on the screen.

A T code consisting of one to four digits is used for controlling the turret.

This control substantially reduces the time required to change tools

because changing the tool, which was conventionally performed in the

machine tool, is done by positioning the turret using the CNC.

For detailed information, refer to the manual prepared by the machine tool

builder.

NOTE

The T-axis can be controlled when TCL, bit 4 of parameter

No. 16260, is 1.

11.4

CONTROLLING THE

TURRET-AXIS

(T-AXIS)
