Series 16i/18i/160i/180i - PB Operators manual Page 659

Operators manual
OPERATION
B–63684EN/01
11. SETTING AND DISPLAYING DATA
633
MULTI TOOL (SHAPE) O0010 N00000
NO. SHAPE(C) SIZE(I) SIZE(J) ANGLE(K)
001 01 10000 0 0
002 01 10000 0 0
003 01 30000 0 0
004 02 20000 10000 0
005 02 22000 10000 0
006 02 21000 9000 0
007 01 15000 0 0
008 01 12000 0 0
009 03 16000 8000 0
010 03 16000 10000 0
>_
MDI **** *** *** 13:53:13
[ SHAPE ][ M.TOOL ][ ][ ][ (OPRT) ]
Fig. 11.4.3.7 Tool figure registration screen for multiple tools
The number indicated on the screen corresponds to the tool registration
number on the tool registration screen for multiple tools (see Item
11.4.3.6).
(2)Setting items from the MDI
1 Set the mode to MDI.
2 Press the
OFFSET
SETTING
function key. Then press the [SETING] soft key
to enable the parameter write operation. The CNC indicates alarm
No. 100.
3 Display the tool figure registration screen for multiple tools by
following the steps described in (1).
4 Move the cursor to an item to be changed.
Method 1
Move the cursor to the item to be changed with the page keys and
cursor keys.
Method 2
Change the mode of the soft keys to the operation selection mode
using the [(OPRT)] soft key. Enter the registration number of the
tool for which data is to be changed, then press the [NO.SRH] soft
key. Move the cursor to the item to be changed with the cursor
keys.
5 For absolute programming, enter the data and press the [INPUT]
soft key.
For incremental programming, enter an increment or decrement
and press the [+INPUT] soft key.
See Item 11.4.3.5 for sub-tool figure data.
