PROGRAMMING

B–63684EN/01

14. FUNCTIONS TO SIMPLIFY

PROGRAMMING

165

The macro function enables commands consisting of several blocks to be

stored in the NC memory as a single macro and to be called when

necessary.

To store several blocks as a single macro, attach numerics of 2 digits (01

to 89) following address work U before commanding several blocks to be

stored and attach the same numerals following address word V after them,

then the several blocks sandwiched in between U and V are stored.

We call the numerics of 2 digits following U or V “macro number”. If the

macro number is any of 01 to 59, then blocks sandwiched in between U

and V are stored with their execution. If the macro number is any of 60

to 89, only storage of blocks is performed without their execution.

;

G92X1830.0Y1270.0 ;

. . . . .

U02 ;

G90X100.0Y500.0T32 ;

G72X150.0Y700.0 ;

G87I100.0J300.0P10.0 ;

N100M100 ;

G72X500.0Y300.0T26 ;

A03G26I100.0J0K4 ;

G72X800.0Y300.0 ;

B03 ;

V02 ;

. . . . .

U70 ;

G90X200.0Y100.0T20 ;

G79I8.0J10.0P3K10 ;

G90X1000.0Y50.0T31 ;

G76I25.0J60.0K6 ;

V70 ;

. . . . .

Storing while command

executing

Storing without command

executing

In the blocks to be sandwiched in between U and V, all commands other

than ones for storage of macros according to other macro numbers (see

example) may be specified. But controller resetting commands, such as

M02, M30, etc., can not be specified. In addition, the part for custom

macros cannot be specified.

Address words U and V must be specified in independent blocks except

for the sequence number (a numeric string of 5 digits following N).

Details of macro numbers 90 to 99 will be described later.

14.4

MACRO FUNCTION

14.4.1

Storage of Macros

Examples
