11. SETTING AND DISPLAYING DATA
649
When the CNC and machine are connected, parameters are set to
determine the specifications and functions of the machine in order to fully
utilize the characteristics of the servo motor. The setting of parameters
depends on the machine. Refer to the parameter list prepared by the
machine tool builder.
Normally, the user need not change parameter setting.
Procedure for displaying and setting parameters
1 Set 1 for PARAMETER WRITE to enable writing. See the procedure
for enabling/disabling parameter writing described below.
2 Press function key
SYSTEM
.
3 Press chapter selection soft key
[PARAM] to display the parameter
screen.
PARAMETER (SETTING) O0010 N00002
0000 SEQ INI ISO TVC
0 0 0 0 0 0 0
0
0001 FCV
0 0 0 0 0 0 0 0
0012 MIR
X 0 0 0 0 0 0 0 0
Y 0 0 0 0 0 0 0 0
Z 0 0 0 0 0 0 0 0
0020 I/O CHANNEL 0
0022 0
> _
THND **** *** *** 16:05:59
[ PARAM ][ DGNOS ][ PMC ][ SYSTEM ][(OPRT)]
4 Move the cursor to the parameter number to be set or displayed in
either of the following ways:
S Enter the parameter number and press soft key
[NO.SRH] .
S Move the cursor to the parameter number using the page keys,
PAGE
and
PAGE
, and cursor keys, , , , and .
5 To set the parameter, enter a new value with numeric keys and press
soft key
[INPUT]. The parameter is set to the entered value and the
value is displayed.
6 Set 0 for
PARAMETER WRITE to disable writing.
11.5.1
Displaying and Setting
Parameters
Previous page
Next page
