Series 16i/18i/160i/180i - PB Operators manual Page 443

Operators manual

Page of 792

/ 792

OPERATION

B–63684EN/01

4. AUTOMATIC OPERATION

417

The following table indicates the relation between other functions and the

movement by handle interrupt.

Signal Relation

Machine lock

Machine lock is effective. When the machine lock signal

is on, handle interrupt is ignored.

Interlock

Interlock is effective. The tool does not move even when

this signal turns on.

Mirror image

Mirror image is not effective. Interrupt functions on the

plus direction by plus direction command, even if this

signal turns on.

The following table shows the relation between various position display

data and the movement by handle interrupt.

Display Relation

Absolute coordinate

value

Handle interruption does not change absolute coor-

dinates.

Relative coordinate

value

Handle interruption does not change relative

coordinates.

Machine coordinate

value

Machine coordinates are changed by the travel dis-

tance specified by handle interruption.

Press the function key

POS

, then press the chapter selection soft key

[HNDL].

The following 4 kinds of data are displayed concurrently.

O0000 N02000

MDI

* * * * * * * * * *

10 : 29 : 51

HANDLE INTERRUPTION

(INPUT UNIT)

(OUTPUT UNIT)

X 69.594 X 69.594

Y 137.783 Y 137.783

C –61.439 C –61.439

(RELATIVE)

X 0.000 X 0.000

Y 0.000 Y 0.000

C 0.000 C 0.000

(DISTANCE TO GO)

PART COUNT 287

RUN TIME 1H 12M CYCLE TIME 0H 0M 0S

ABS

REL ALL (OPRT)

HNDL

Explanations

D Relation with other

functions

D Position display

D Travel distance display
