PROGRAMMING13. PROGRAM CONFIGURATION

B–63684EN/01

130

A block consists of one or more words. A word consists of an address

followed by a number some digits long. (The plus sign (+) or minus sign

(–) may be prefixed to a number.)

Word = Address + number (Example : X–1000)

For an address, one of the letters (A to Z) is used ; an address defines the

meaning of a number that follows the address. Table 13.2 (b) indicates

the usable addresses and their meanings.

The same address may have different meanings, depending on the

preparatory function specification.

Table 13.2 (b) Major functions and addresses

Function Address Meaning

Program number O

(Note)

Program number

Sequence number N Sequence number

Preparatory function G Specifies a motion mode (linear, arc,

etc.)

Dimension word X, Y, Z, U,

V, W, A, B,

Coordinate axis move command

I, J, K Coordinate of the arc center

R Arc radius

Feed function F Rate of feed per minute,

Rate of feed per revolution

Spindle speed function S Spindle speed

Tool function T Tool number

Auxiliary function M On/off control on the machine tool

B Table indexing, etc.

Offset number D, H Offset number

Dwell P, X Dwell time

Program number

designation

P Subprogram number

Number of

repetitions

P Number of subprogram repetitions

Parameter P, Q Canned cycle parameter

Macro function A, B, U, V,

Specifies macro number

NOTE

In ISO code, the colon ( : ) can also be used as the address

of a program number.

G_ X_ Y_ F_ S_ T_ M_

;

Sequence

number

Preparatory

function

Dimension

word

Feed–

function

Spindle

speed

function

Tool

function

Miscellaneous

function

Fig.13.2 (c) 1 block (example)

D Block configuration

(word and address)
