OPERATION

B–63684EN/01

11. SETTING AND DISPLAYING DATA

599

Displays the block currently being executed and modal data in the

MEMORY or MDI mode.

Procedure for displaying the current block display screen

1 Press function key

PROG

2 Press chapter selection soft key

[CURRNT].

The block currently being executed and modal data are displayed.

The screen displays up to 22 modal G codes and up to 11 G codes

specified in the current block.

MEM STRT MTN FIN 15:06:52

[ PRGRM ][ CHECK ][ CURRNT ][ NEXT ][ ]

PROGRAM O1000 N00110

(CURRENT) (MODAL)

G00 .X 15.000 G00 F

G90 .Y 15.000 G17

T 2 G90 M

G22

G21

G40 H D

G50

G67 T 2

G54

G64 S

G85

The current block display screen is not provided for 12–soft key type LCD.

Press soft key

[PRGRM] to display the contents of the program on the right

half of the screen. The block currently being executed is indicated by the

cursor. Modal data is displayed on the left half of the screen.

The screen displays up to 18 modal G codes.

ACTUAL POSITION

(ABSOLUTE)

X 0.000

Y 0.000

C 30.000

G00 G40 G54 F 500 M 3

G17 G43 G64

G90 G80 G69 H 5

G22 G90 G15 D T 9

G94 G50 G25

G21 G67 S 6000

SACT 0

O3001 N00000

F 0

ABS

REL ALL

PRGRM

(OPRT)

PROGRAM

O3001 ;

G40 ;

G49 M06 T9 ;

G0 G54 G90 X0 Y0 ;

G43 Z30. H5 S6000 M3 ;

M0 ;

X17.5 Y–22 ;

Z–6.5 ;

G10 P11 R0.995 F500 ;

M30 ;

MEM **** *** *** 07:07:40

(MODAL)

MM/MIN

11.2.2

Current Block Display

Screen

Procedure

Explanations
