APPENDIXG. ALARM LIST
B–63684EN/01
720
Number ContentsMessage
033 NO SOLUTION AT CRC A point of intersection cannot be determined for cutter compensation C.
Modify the program.
034 NO CIRC ALLOWED IN ST–UP /EXT
BLK
The start up or cancel was going to be performed in the G02 or G03
mode in cutter compensation C. Modify the program.
036 CAN NOT COMMANDED G31 Skip cutting (G31) was specified in cutter compensation mode.
Modify the program.
037 CAN NOT CHANGE PLANE IN CRC G40 is commanded on the plane other than offset plane in cutter com-
pensation B. The plane selected by using G17, G18 or G19 is changed
in cutter compensation C mode. Modify the program.
038 INTERFERENCE IN CIRCULAR
BLOCK
Overcutting will occur in cutter compensation C because the arc start
point or end point coincides with the arc center.
Modify the program.
041 INTERFERENCE IN CRC Overcutting will occur in cutter compensation C. Two or more blocks
are consecutively specified in which functions such as the auxiliary
function and dwell functions are performed without movement in the cut-
ter compensation mode. Modify the program.
059 PROGRAM NUMBER NOT FOUND In an external program number search, a specified program number
was not found. Otherwise, a program specified for searching is being
edited in background processing. Check the program number and ex-
ternal signal. Or discontinue the background eiting.
060 SEQUENCE NUMBER NOT FOUND Commanded sequence number was not found in the sequence number
search. Check the sequence number.
070 NO PROGRAM SPACE IN MEMORY The memory area is insufficient.
Delete any unnecessary programs, then retry.
071 DATA NOT FOUND The address to be searched was not found. Or the program with speci-
fied program number was not found in program number search.
Check the data.
072 TOO MANY PROGRAMS The number of programs to be stored exceeded 63 (basic), 125, 200,
400 (option), or 1000 (option). Delete unnecessary programs and
execute program registeration again.
073 PROGRAM NUMBER ALREADY IN
USE
The commanded program number has already been used.
Change the program number or delete unnecessary programs and
execute program registeration again.
074 ILLEGAL PROGRAM NUMBER The program number is other than 1 to 9999.
Modify the program number.
075 PROTECT An attempt was made to register a program whose number was pro-
tected.
076 ADDRESS P NOT DEFINED Address P (program number) was not commanded in the block which
includes an M98, G65, or G66 command. Modify the program.
077 SUB PROGRAM NESTING ERROR The subprogram was called in five folds. Modify the program.
078 NUMBER NOT FOUND A program number or a sequence number which was specified by ad-
dress P in the block which includes an M98, M99, M65 or G66 was not
found. The sequence number specified by a GOTO statement was not
found. Otherwise, a called program is being edited in background pro-
cessing. Correct the program, or discontinue the background editing.
079 PROGRAM VERIFY ERROR In memory or program collation,a program in memory does not agree
with that read from an external I/O device. Check both the programs in
memory and those from the external device.
085 COMMUNICATION ERROR When entering data in the memory by using Reader / Puncher interface,
an overrun, parity or framing error was generated. The number of bits
of input data or setting of baud rate or specification No. of I/O unit is in-
correct.
