Series 16i/18i/160i/180i - PB Operators manual Page 785

Operators manual

Page of 792

/ 792

B–63684EN/01

Index

i–3

External Motion Function, 102

External Operator Message History Display, 656

External Output Commands, 295

[F]

F1–digit (Programmable Rapid Traverse Override), 48

FANUC Handy File, 379

Feed Functions, 43

Feed–Feed Function, 12

Feedrate Clamping by ARC Radius, 313

Feedrate Override, 440

File Deletion, 480

File Search, 479

Files, 477

Floating Reference Position Return (G30.1), 68

Function Keys, 356

Function Keys and Soft Keys, 355

Functions to Simplify Programming, 140

[G]

G00 Command in Nibbling Mode, 97

G01, G02, and G03 Commands in Nibbling Mode, 98

G53, G28, G30, G30.1 and G29 Commands in Cutter

Compensation C Mode, 225

General Flow of Operation of CNC Machine Tool, 5

General Screen Operations, 355

Glossary, 738

Graphic Display, 345

Graphic Display Screen and Drawing, 668

Graphics Function, 660

Grid (G78, G79), 147

[H]

Heading a Program, 548

Helical Interpolation (G02, G03), 42

Help Function, 673

High Speed Cutting Functions, 312

High Speed Skip Signal (G33), 41

How to Indicate Command Dimensions for Moving

the Tool – Absolute, Incremental Commands, 16

How to View the Position Display Change without

Running the Machine, 338

[I]

Inch/Metric Conversion (G20, G21), 80

Increment System, 25, 322

Incremental Command Just After Pattern Function,

154

Incremental Feed, 388

Input Command from MDI, 224

Input of Measured Workpiece Origin Offsets, 643

Inputting a Program, 481

Inputting and Outputting Floppy Files, 518

Inputting and Outputting Offset Data, 515

Inputting and Outputting Parameters, 513

Inputting and Outputting Parameters and Pitch Error

Compensation Data, 488

Inputting and Outputting Programs, 508

Inputting Custom Macro Common Variables, 492

Inputting Offset Data, 486

Inputting Parameters, 488

Inputting Pitch Error Compensation Data, 490

Inputting Tool Data, 502

Inputting/Outputting Custom Macro Common Vari-

ables, 492

Inputting/Outputting Tool Data, 502

Inserting a Word, 549

Inserting Altering and Deleting a Word, 545

Inside–corner Override (G62), 53

Interference Check, 218

Internal Circular Cutting Feedrate Change, 55

Interpolation Functions, 30

Interruption Type Custom Macro, 299

[J]

Jog Feed (Jog), 386

[K]

Key Input and Input Buffer, 374

[L]

Limitation and Notes, 433

Limitations, 294
