PROGRAMMING

B–63684EN/01

16. CUSTOM MACRO

265

Workpiece zero point offset values can be read and written.

Table 16.2 (j) System variables for workpiece zero point offset values

Variable

number

Function

#5201

#5208

First–axis external workpiece zero point offset value

Eighth–axis external workpiece zero point offset value

#5221

#5228

First–axis G54 workpiece zero point offset value

Eighth–axis G54 workpiece zero point offset value

#5241

#5248

First–axis G55 workpiece zero point offset value

Eighth–axis G55 workpiece zero point offset value

#5261

#5268

First–axis G56 workpiece zero point offset value

Eighth–axis G56 workpiece zero point offset value

#5281

#5288

First–axis G57 workpiece zero point offset value

Eighth–axis G57 workpiece zero point offset value

#5301

#5308

First–axis G58 workpiece zero point offset value

Eighth–axis G58 workpiece zero point offset value

#5321

#5328

First–axis G59 workpiece zero point offset value

Eighth–axis G59 workpiece zero point offset value

NOTE

Variables #5201 to #5328 are optional variables for the

workpiece coordinate systems.

D Workpiece coordinate

system compensation

values (workpiece zero

point offset values)
