Series 16i/18i/160i/180i - PB Operators manual Page 751

Operators manual
APPENDIX
B–63684EN/01
G. ALARM LIST
725
Number ContentsMessage
4539 MULTI-PIECE SETTING IS ZERO The command for taking multiple workpieces (G73, G74) was specified
although zero is specified for the function to take multiple workpieces
(No. 16206 or signals MLP1 and MLP2 (PMC address G231, #0 and
#1)).
4540 MULTI-PIECE COMMAND WITHIN
MACRO
The command for taking multiple workpieces (G73, G74) was specified
when a U or V macro was being stored.
4542 MULTI-PIECE COMMAND ERROR Although G98P0 was specified, the G73 command was issued.
Although G98K0 was specified, the G74 command was issued.
4543 MULTI-PIECE Q COMMAND
ERROR
Although G98P0 was specified, the Q value for the G74 command was
not 1 or 3.
Although G98K0 was specified, the Q value for the G73 command was
not 1 or 2.
4544 MULTI-PIECE RESTART ERROR In the command for resuming taking multiple workpieces, the resume
position (P) is set to a value beyond the range from 1 to total number of
workpieces to be machined.
4549 ILLEGAL TOOL DATA FORMAT The quantity of tool data patterns to be saved is too large to fit the usable
area (16 KB).
4600 T, C COMMAND IN
INTERPOLATION
In the linear interpolation (G01) mode or circular interpolation (G02,
G03) mode, a T command or C-axis command was specified.
4601 INHIBITED T, M COMMAND In the block of G52, G72, G73, or G74, a T or M command was specified.
4602 ILLEGAL T-CODE The specified T command is not cataloged on the tool register screen.
4603 C AXIS SYNCHRONOUS ERROR The difference between the position deviation value of C1 axis and C2
axis exceeds the parameter value (No. 16364, 16365) with the C–axis
synchronous control function.
4604 ILLEGAL AXIS OPERATION A C-axis command was specified in the block containing a T command
for multiple tools.
4605 MAKE A RETURN TO THE REF-
ERENCE POSITION ON THE
C–AXIS
Make a manual return to the reference position on the C–axis.
4606 A T COMMAND WAS ISSUED A T command was issued during normal–line control.
4630 ILLEGAL COMMAND IN LASER
MODE
In the laser mode, a nibbling command or pattern command was speci-
fied.
In the tracing mode, an attempt was made to make a switch to the
punching mode.
4631 ILLEGAL COMMAND IN PUNCH
MODE
In the punching mode, a G code of laser control (G13, G24, G31, etc.)
was specified.
4650 IMPROPER G-CODE IN OFFSET
MODE
In the cutter compensation mode, an inhibited G code (pattern com-
mand, G73, G74, G75, etc.) was specified.
4700 PROGRAM ERROR (OT +) The value specified in the X-axis move command exceeded the positive
value of stored stroke limit 1. (Advance check)
4701 PROGRAM ERROR (OT –) The value specified in the X-axis move command exceeded the nega-
tive value of stored stroke limit 1. (Advance check)
4702 PROGRAM ERROR (OT +) The value specified in the Y-axis move command exceeded the positive
value of stored stroke limit 1. (Advance check)
4703 PROGRAM ERROR (OT –) The value specified in the Y-axis move command exceeded the nega-
tive value of stored stroke limit 1. (Advance check)
4704 PROGRAM ERROR (OT +) The value specified in the Z-axis move command exceeded the positive
value of stored stroke limit 1. (Advance check)
4705 PROGRAM ERROR (OT –) The value specified in the Z-axis move command exceeded the nega-
tive value of stored stroke limit 1. (Advance check)
