2.MECHANICAL DESIGN HANDLING, DESIGN, AND ASSEMBLY B-65222EN/03
- 124 -
2.17 NAMEPLATE ATTACHMENT AND SERIAL NUMBER
MANAGEMENT
One of the nameplates shown below and a laminated sheet are packed
together with the coil sliders of all models.
FANUC nameplate GE Fanuc nameplate
For maintenance, attach the nameplate to the following location
where:
- The nameplate is always visible at the time of maintenance.
- The nameplate is easily visible without removing components.
- The nameplate is not easily detached.
Next, to protect the nameplate, attach the laminated sheet over the
nameplate. The recommended nameplate attachment locations
include:
- Inside of the door of the cabinet
- Near the main power supply of the machine
- Near the operator's panel or the back of the operator's panel
In addition, record and keep the combinations of machine numbers
and motor serial numbers so that which machine incorporates a motor
of which serial number can be identified easily after machine
shipment.
