Linear Motor Series Descriptions Page 247

Descriptions
Title
Sheet
Draw. No.
FANUC LINEAR MOTOR series
DESCRIPTIONS (Detector)
7／16
FANUC LTD
B-65222EN/03-003
DescriptionDesig.DateEdit.
01 02.05.13 KIKUCHI
(1)-b Cable K2 (A860-0333-T002 : Two Serial Data Outputs)
Recommended ｗire 5V,0V ・・・・・・・・・・・・・・0.5mm
2
×３ or more
SD1,XSD1,SD2,XSD2,REQ,XREQ・・0.18 mm
2
Recommended cable A66L-0001-0286
(Note) SD2,XSD2 are equal logic signals to SD1,XSD1, but drived by different drivers.
SD1,XSD1 and SD2,XSD2 are connected to different DSP axes.
SHIELD
(9),(10),(11)
(12),(13),(14)
(15)
SD1
REQ
XSD1
0V
XREQ
5V
(3)
(4)
(1)
(2)
Linear Motor
Position Detection
Circuit H
Connect to Earth Bar
HIROSE RM21WTP-15S-(8)
SD2
XSD2
(5)
(6)
Connect to Earth Bar
A
xis(2N-1)
(DSP N)
A
xis(2N+1)
(DSP N+1)
（note）
N:Plus Integer
Servo Amplifier
(As for the connection
of Servo Amplifire side,
refer the manual of
Descriptions of Servo
Amplifire)
