Series 0i Mate - MB Operators manual Page 202

Operators manual
PROGRAMMING14. COMPENSATION FUNCTION
B–63864EN/03
178
14
COMPENSATION FUNCTION
This chapter describes the following compensation functions:
14.1 TOOL LENGTH OFFSET (G43, G44, G49)
14.2 AUTOMATIC TOOL LENGTH MEASUREMENT (G37)
14.3 TOOL OFFSET (G45–G48)
14.4 OVERVIEW OF CUTTER COMPENSATION C (G40–G42)
14.5 DETAILS OF CUTTER COMPENSATION C
14.6 TOOL COMPENSATION VALUES, NUMBER OF
COMPENSATION VALUES, AND ENTERING VALUES FROM
THE PROGRAM (G10)
14.7 SCALING (G50, G51)
14.8 COORDINATE SYSTEM ROTATION (G68, G69)
14.9 PROGRAMMABLE MIRROR IMAGE (G50.1, G51.1)
