APPENDIX

B–63864EN/03

G. ALARM LIST

809

SPM

indica-

tion(*1)

DescriptionFaulty location and remedy

12 During execution of the spindle synchronization com-

mand, do not specify another operation mode. Before

entering another mode, cancel the spindle synchro-

nization command.

Although spindle synchronization is being performed,

another operation mode (Cs contour control, servo

mode, or orientation) is specified.

13 During execution of the orientation command, do not

specify another operation mode. Before entering

another mode, cancel the orientation command.

Although the orientation command is being executed,

another operation mode (Cs contour control, servo

mode, or synchronization) is specified.

14 Input the SFT or SRV signal. The SFT and SRV signals are both input at the same

time.

15 Check bit 5 of parameter No. 4000 and PMC signal

(CON).

When bit 5 of parameter No. 4000 is set to 1 to indi-

cate the presence of the differential speed mode

function, Cs contour control is specified.

16 Check bit 5 of parameter No. 4000 and PMC signal

(DEFMD).

When bit 5 of parameter No. 4000 is set to 0 to indi-

cate the absence of the differential speed mode func-

tion, the differential speed mode command (DEFMD)

is input.

17 Check bits 2, 1, and 0 of parameter No. 4011. Setting of the speed detector parameter (bits 2, 1,

and 0 of parameter No. 4011) is invalid. (The corre-

sponding speed detector is not present.)

18 Check bit 2 of parameter No. 4001 and PMC signal

(ORCM).

Although bits 2 of parameter No. 4001 is set to 0 not

to use the position coder signal, a command for

orientation by a position coder (ORCMA) is input.

19 During execution of the orientation command, do not

specify another operation mode. Before entering

another mode, cancel the orientation command.

Although orientation by a magnetic sensor is being

performed, another operation mode is specified.

20 Check bit 5 of parameter No. 4001, bit 5 of parameter

No. 4014, and bit 4 of parameter No. 4018.

When the use of the slave operation mode function is

set (bit 5 of parameter No. 4014 = 1), the use of a

high–resolution magnetic pulse coder (bit 5 of param-

eter No. 4001 = 1) or the use of the Cs contour con-

trol function by the sensor (bit 4 of parameter No.

4018 = 1) is specified. These items cannot be set at

the same time.

21 Input the slave operation mode command (SLV) in nor-

mal operation mode.

Although position control (such as servo mode or

orientation) is being performed, a slave operation

mode command (SLV) is input.

22 Input the position control command in normal operation

mode

Although slave operation mode is set (SLVS = 1), a

position control command (such as servo mode or

orientation) is input.

23 Check bit 5 of parameter No. 4014 and PMC signal

(SLV).

Although bit 5 of parameter No. 4014 is set to 0 not to

use the slave operation mode function, a slave op-

eration mode command (SLV) is input.

24 Check the PMC signal (INCMD). Perform orientation

by specifying an absolute position first.

Orientation is performed in incremental operation

mode (INCMD = 1) first, then the absolute position

command (INCMD = 0) is input.

25 Check the spindle amplifier specifications and parame-

ter setting (bit 4 of parameter No. 4018).

Although the spindle amplifier SPM type 4 is not

used, the use of the Cs contour control function by

the sensor is set (bit 4 of parameter No. 4018 = 1).

NOTE*2

PSM contact signal

Between ESP1 and ESP2 on the PSM Contact open: Emergency stop

Contact closed: Normal operation
