1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63864EN/03

- 704 -

Example of data entering for contour figure

If you select a line, the line screen is displayed, allowing you to enter

all the figure data written on a drawing.

Even though the end point coordinate value does not appear in a

drawing, it can be determined by calculating the cross point

coordinate between this figure and that to be entered next.

Data item Comment

END POINT X X coordinate of a line end point

END POINT Y Y coordinate of a line end point

ANGLE A Angle of line from +X-axis. A positive angle is counter

clockwise direction.

TOUCH STATE Select from the following soft-key menu whether

tangential or not between neighbor figure.

[NO] : Not tangential

[LAST] : Tangential with the preceding figure

FEEDRATE Feedrate

NOTE

The feedrate data item is displayed when parameter

No.9341#3(FCD) is set to 1.

[AUX.] : Call auxiliary calculating screen. The result of it will be

set into end point coordinate or angle data.

[OFFSET] : Call a cutter compensation setting screen. (Available at

only when a parameter No.9341#5(DCD) is set to 1)

[OK] : Fix line figure data and store into memory.

[CANCEL] : Cancel line figure data entering and return to the

contour program list screen.

Modify contour figures

There are two ways of modifying contour figure data that has already

been fixed and stored.

Method 1

Use a contour figure data screen

On the contour program list screen, position the cursor to the figure

block that is to be modified, and then press [MODIFY]. The figure

data screen corresponding to the selected figure is displayed, allowing

you to enter new data. Enter the required new data and then press

[OK]. Then, press [RECALC] to calculate all of the contour figures

by using the newly entered data.

Method 2

Modify the data directly on a contour program list screen

On the contour program list screen, position the cursor to the data that

is to be modified, enter a new value, and then press INPUT.

Then, press [RECALC] to calculate all of the contour figures by using

the newly entered data.

NOTE

To clear a data entry, press CAN and then INPUT.
