Series 0i Mate - MB Operators manual Page 676

Operators manual

Page of 842

/ 842

OPERATION12. GRAPHICS FUNCTION

B–63864EN/03

652

Path drawing procedure

1 To draw a tool path, necessary data must be set beforehand.

So press the function button

GRAPH

some times (

CUSTOM

GRAPH

for the small

MDI).The “PATH GRAPHIC (PARAMETER)” is displayed.

MDI

* * * *

* * * * * *

14 : 25 : 07

PATH GRAPHIC (PARAMETER–1) O0000 N00002

AXES P=

(XY=0, YZ=1, ZY=2, XZ=3, XYZ=4, ZXY=5, 2P=6)

ANGLE

ROTATION A= 0

TILTING A= 0

SCALE K= 0.00

CENTER OR MAX./MIN.

X=130.000 Y= 110.000 Z= 50.000

I= 0.000 J= –10.000 K= 0.000

START SEQ. NO. N= 0

END SEQ. NO. N= 0

NO. A=

PARAM

POS

EXEC

SCALE

MDI

* * * *

* * * * * *

14 : 25 : 51

PATH GRAPHIC (PARAMETER–2) O0000 N00001

TOOL. COMP P=

COLOR (0123456)

PATH P= 0

TOOL Q= 0

AUTO CHANGE R= 0

PARAM

POSEXEC SCALE

2 There are two screens for setting drawing parameters.

Press the page key according to the setting items for selecting

screens.

3 Set the cursor to an item to be set by cursor keys.

4 Input numerics by numeric keys.

5 Press the

INPUT

key.

The input numerics are set by these operations and the cursor

automatically moves to the next setting items. The set data is held even

after the power is turned off.

Procedure
