B-63864EN/03 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i

- 687 -

Line (Not Equal interval) - Hole pattern : G1212

Data item Comment

B REFERENCE POSITION Z-coordinate of the workpiece surface

L DEPTH Hole depth (usually negative value)

H START POINT (X-AXIS) Start point X-coordinate of the line (1st hole point)

V START POINT (Y-AXIS) Start point Y-coordinate of the line (1st hole point)

A ANGLE Angle of the line

C PITCH WIDTH-1 Distance on the line between 1st hole point and 2nd

hole point (positive value only)

D PITCH WIDTH-2 Distance on the line between 2nd hole point and 3rd

hole point (positive value only)

E PITCH WIDTH-3 Distance on the line between 3rd hole point and 4th

hole point (positive value only)

F PITCH WIDTH-4 Distance on the line between 4th hole point and 5th

hole point (positive value only)

I PITCH WIDTH-5 Distance on the line between 5th hole point and 6th

hole point (positive value only)

J PITCH WIDTH-6 Distance on the line between 6th hole point and 7th

hole point (positive value only)

K PITCH WIDTH-7 Distance on the line between 7th hole point and 8th

hole point (positive value only)

M PITCH WIDTH-8 Distance on the line between 8th hole point and 9th

hole point (positive value only)

P PITCH WIDTH-9 Distance on the line between 9th hole point and 10th

hole point (positive value only)

Q PITCH WIDTH-10 Distance on the line between 10th hole point and

11th hole point (positive value only)

NOTE

It is not necessary to enter all of the PITCH WIDTH

data item.
